Technical Specification

RUGGEDIZATION
• IP-68 certication, submersible up to 2 metres for 1 hour
• External speaker protected by waterproof GORE™ Protective Vents
• MIL-810G certication (incl. salt, humidity, transport shock & thermal shock)
• Hardened rubber molded to Fiberglass casing mix by dual injection
• Rated to 2 metre drops onto concrete from any angle
• Vibration protection from 5Hz to 500Hz and shock resistant up to 4G
• Non-porous casing blocks entry of dust and micro-particles
• Operational range -20°C to +55°C
• Shock & scratch resistant 1.5mm thick Corning® Gorilla® Glass screen
• Widely spaced keys for ease of use with gloved hands
• Impact resistant up to 5J on housing and 2J of impact energy on
screen (equivalent of a 4 metre drop of a 50g steel ball on the display)

KEY FEATURES
• 3G HSPA/GSM/GPRS/EDGE
• Packet Switch Push-to-talk (single & group calls, presence/availability)
• 2 inch bright (typ. 280cd/m²) high-resolution display for high visibility
• Noise-cancelling microphone
• GPS, A-GPS with SUPL
• JAVA MIDP 2.0/CLDC 1.1 device
• 2 MP still camera with LED Flash and video recording capability
• LED torch light
• MicroSD card slot (up to 16 GB card)
• Media Player
• FM Radio

BATTERY
• 1950 mAh battery with talk time of up to 12Hrs on 3G Network and
standby time up to 875 Hrs.
• GPS Navigator: 11Hrs on 3G Network

PHYSICAL CHARACTERISTICS
• Size: 126mm x 60mm x 25mm
• Weight: 190 grams
• GCF/CE certications
• 7 soft keys/10 programmable short-cuts
• 3.5mm waterproof headset and USB data ports (proprietary cable)
• Dedicated PTT/Navigator key, volume keys and camera key

DISPLAY
• 2 inch, QVGA 240x320 resolution
• 30x40mm for display bar + 10 rows of data

AUDIO SYSTEM
• One single 23mm diameter water resistant speaker
specially designed for higher volume transmission
and reception
• Omni-directional microphone with noise cancellation

MULTIMEDIA
Audio Formats:
• MP3 • AAC+
• AAC
• WAV

SOFTWARE PACKAGE
• Standard services
SMS (incl. T9, Multitap modes), MMS 1.3
WAP 2.0 with support for WSP and HTTP
Polyphonic ring tone supported (MIDI)
MP3 ringtone support
• Native Email Client - POP3/SMTP, IMAP4 and
secure Email support (SSL/TLS)
• HTML web browser
• TeleNav®, turn-by-turn navigation application
• Self Serve®: Account Management, Trouble

Shooting
STANDARD ACCESSORIES
• Electrical wall charger
• Screwdriver
• Stereo wired headset
• USB cable
• 3.5 mm to USB adaptor

OPTIONAL ACCESSORIES
• Car charger
• Belt clip
• Rugged pouch
THIRD PARTY BLUETOOTH ACCESSORIES
© 2012 by Sonim Technologies, Inc. All right reserved.
BOLT
TECHNICAL SPECIFICATIONS
5520
Video Formats:
• 3gp
• MPEG4 (simple prole)

THIRD PARTY BLUETOOTH ACCESSORIES
© 2012 by Sonim Technologies, Inc. All right reserved.
BOLT
TECHNICAL SPECIFICATIONS
5520
Video Formats:
• 3gp
• MPEG4 (simple prole)
Samsung WEP 460
Motorola:
H390, H350
Nokia:
BH-216, BH-109
BH-105, BH-803
Nokia CK15W
Blueant supertooth light

• Bluetooth headsets:
BlackBerry:
HS-300 , HS-500
Plantronics:
Discovery 975
Voyager PRO+
Sony Ericsson VH310
Jabra:
Stone, Wave, Clipper
• Bluetooth Carkits:
Motorola T305
